HOISTING WIRE ROPE

The wire rope for hoisting with various constructions of multi-layer, linear and facial contacted structure can meet the demand in cranes, harbor and metallurgy.


Norminal diameter mm	ApproxWeight kg/100m	NominalStrength MPa
		1570	1670	1770	1870	1970
		Min.Breaking Load kN
8 10 12 13 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52 54 56 58 60	26.8 41.8 60.2 70.6 81.9 107 135 167 202 241 283 328 376 428 483 542 604 669 737 809 884 963 1040 1130 1220 1310 1410 1500	35.8 55.9 80.5 94.5 110 143 181 224 271 322 378 438 503 572 646 724 807 894 986 1080 1180 1290 1400 1510 1630 1750 1880 2010	38.0 59.5 85.6 100 117 152 193 238 288 342 402 466 535 609 687 770 858 951 1050 1150 1260 1370 1490 1610 1730 1860 2000 2140	40.3 63.0 90.7 106 124 161 204 252 305 363 426 494 567 645 728 817 910 1010 1110 1220 1330 1450 1580 1700 1840 1980 2120 2270	42.6 66.6 95.6 113 130 170 216 266 322 383 450 522 599 682 770 863 961 1070 1170 1290 1410 1530 1660 1800 1940 2090 2240 2400	44.7 69.8 100 118 137 179 226 279 338 402 472 547 628 715 807 904 1010 1120 1230 1350 1480 1610 1740 1890 2030 2190 2350 2510
Note:The total Min.breakingload=Min.breaking load X1.321(steel core)


Norminal diameter mm	ApproxWeight kg/100m	NominalStrength MPa
		1570	1670	1770	1870
		Min.Breaking Load kN
16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52 54 56 58 60	122 155 191 231 275 322 374 429 488 551 618 689 763 841 923 1010 1100 1190 1290 1390 1500 1600 1720	165 209 257 312 371 435 505 579 659 744 834 930 1030 1140 1250 1360 1480 1610 1740 1880 2020 217 2320	175 222 274 331 394 463 537 616 701 792 887 989 1100 1210 1330 1450 1580 1710 1850 2000 2150 2300 2460	186 235 290 351 418 491 569 653 743 839 941 1050 1160 1280 1400 1540 1670 1810 1960 2120 2280 2440 2610	196 248 307 371 442 518 601 690 785 886 994 1110 1230 1350 1480 1620 1770 1920 2070 2240 2400 2580 2760
Note:The total Min.breakingload=Min.breaking load X 1.321


Norminal diameter mm	ApproxWeight kg/100m	NominalStrength MPa
		1570	1670	1770	1870
		Min.Breaking Load kN
18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52 54 56 58 60 62 64 66 68 70	160 198 240 285 335 388 446 507 572 642 715 792 873 958 1050 1140 1240 1340 1440 1550 1670 1780 1900 2030 2160 2290 2430	209 257 312 371 435 505 579 659 744 834 930 1030 1140 1250 1360 1480 1610 1740 1880 2020 2170 2320 2470 2640 2800 2980 3150	222 274 331 394 463 537 616 701 792 887 989 1100 1210 1330 1450 1580 1710 1850 2000 2150 2300 2460 2630 2800 2980 3170 3360	235 290 351 418 491 569 653 743 839 941 1050 1160 1280 1400 1540 1670 1810 1960 2120 2280 2440 2610 2790 2970 3160 3360 3560	248 307 371 442 518 601 690 785 886 994 1110 1230 1350 1480 1620 1770 1920 2070 2240 2400 2580 2760 2950 3140 3340 3550 3760
Note:The total Min.breakingload=Min.breaking load X 1.374


Norminal diameter mm	ApproxWeight kg/100m	NominalStrength MPa
		1570	1670	1770	1870	1960
		Min.Breaking Load kN
20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52 54 56 58 60	204 247 294 345 400 459 522 590 661 736 816 900 987 1080 1180 1280 1380 1490 1600 1720 1840	257 312 371 435 505 579 659 744 834 930 1030 1140 1250 1360 1480 1610 1740 1880 2020 2170 2320	274 331 394 463 537 616 701 792 887 989 1100 1210 1330 1450 1580 1710 1850 2000 2150 2300 2460	290 351 418 491 569 653 743 839 941 1050 1160 1280 1400 1540 1670 1810 1960 2120 2280 2440 2610	307 371 442 518 601 690 785 886 994 1110 1230 1350 1480 1620 1770 1920 2070 2240 2400 2580 2760	321 389 463 543 630 723 823 929 1040 1160 1290 1420 1560 1700 1850 2010 2170 2340 2520 2700 2890
Note:The total Min.breakingload=Min.breaking load X 1.287
